UltraClean FR series reverse osmosis membrane elements have strong anti-scaling performance and anti-organic and microbial pollution performance. They are mainly used to treat water sources with high pollution tendency, such as printing and dyeing wastewater and industrial wastewater from thermal power plants. Through the special composite membrane preparation technology, the charge and smoothness of the membrane surface are changed, and the hydrophilic performance of the membrane surface is enhanced, thereby reducing the pollutants and microorganisms attached to the surface layer, thereby reducing the fouling rate of membrane elements and prolonging the membrane service life. The UltraClean FR series is available in 8-inch and 4-inch sizes.
Stable performance and high rejection rate for organics
Low operating pressures, high flux and cost saving
Meet the demand for near zero discharge
Operating and Cleaning Limits
|Maximum Operating Pressure||41 bar (600 psi)|
|Maximum Operating Temperature||45°C (113°F )|
|Maximum Element Pressure Drop||1.0 bar (15psi)|
|pH Range Continuous Operation||2-11|
|pH Range Short-Term Cleaning||1-13|
|Maximum Feed SDI(SDI15)||5.0|
|Free Chlorine Tolerance||< 0.1 ppm|
Permeate flow for individual elements may vary ±15 percent from the value specifed.
Active membrane area guaranteed ±4%.
Stabilized salt rejection is generally achieved within 24-48 hours of continuous use; depending upon feedwater characteristics and operating conditions.
|Effective Membrane Area|
|400 (37)||99.5||99.0||10500 (40)|
Test conditions: inlet pressure 1.55 MPa (225 psi); inlet temperature 25°C (77°F); inlet water quality 2000ppm NaCl; inlet pH 8; recovery 15%.
